Buzz is the bane of the guitarist. Fret-buzz is the one that gets all the press and, to be sure, it’s a serious pain. Frets are not the only thing that is likely to buzz, rattle and hum on your guitar though. If you’ve got a Gibson (or Gibsonesque – the one below is a Gretsch) guitar it’s possible that your Tune-O-Matic bridge may be the cause of that buzz you hear.
If you can hear a metallic rattle or buzz when you pick a note – sometimes all notes, sometimes certain notes or strings – it’s worth checking your bridge.
The ABR style Tune-O-Matic bridge (the vintage style one) has six adjustable saddles held in place by a small retainer wire. As you can see in the photo, the wire runs across the top of all six saddle-adjustment screws and anchors in a tiny hole either end of the bridge.
G String Buzzing On Your Classical Guitar? Fix It
This is all very good and ‘vintage’ until it starts to rattle. If you’re having trouble tracking down a buzz, try damping the retainer wire in some way to determine if that’s the cause. Pop a bit of tape on temporarily or have a friend poke their finger on it while you play – whatever you need to see if the bridge is the issue.
Once you determine you are actually afflicted by a buzzing bridge, all that’s necessary is to use a small, flat-head screwdriver to push down on the retaining wire between all six saddles. Doing this forces a slight kink into the wire which tightens the wire and forces it more snuggly against the saddle screws.
I recommend going from one end to the other and kinking gradually rather than forcing large kinks in all in one go. It’s possible to force one or more too far and affect their ‘saddle holding’ ability so go slow.
The Perfect Jaguar Setup? Part Two. Let's Face It. It's The Bridge
Take it easy and carefully. You should consider it a necessity to cut some thick card (a couple of thicknesses is best) to place on the guitar top, under the bridge. It’s incredibly easy to slip and stab your AAAAA-grade quilted maple top with a screwdriver blade. You don’t want that. Protect the guitar before you start jabbing screwdrivers at it.
All going well, you should have a nice, silent retainer wire. Some wires require more persuasion than others to shut-up and it’s not uncommon to have to ‘re-kink’ from time to time after you do it as it works its way loose again. If you really mess up it’s possible to make a new retainer from a guitar string although it’s probably easier to just buy a new, ready-bent-to-shape wire.
This article was brought to you by Gerry Hayes from the workshop of Haze Guitars. Haze Guitars provides instrument repair, restoration and upgrade services in Dublin, Ireland.A few weeks ago, I discussed a problem over email with someone. It was something I’d seen a number of times over the years so I thought it’d be worth getting into here too.
Fret Buzz, Why It Happens And How To Fix It
On an acoustic guitar, the bridge is typically glued to the guitar soundboard. Sometimes the string tension can begin to separate these parts. This often manifests as a lifting bridge — a gap develops at the rear of the bridge as the strings try to pull it from the body. If it's not dealt with, this glue joint can fail completely and the bridge can be pulled off the body completely. Never fun.
Pinless bridges (where the strings are not anchored through the bridge and soundboard and wedged in with bridge pins) tend to exacerbate this issue. Anchoring the string ball-ends at the rear of the bridge —above the guitar top—brings introduces a whole other kettle of physics.
So, guitar makers sometimes add some reinforcement to the glue joint. This is more common with pinless bridges but you'll find it on regular bridges too.
Factory Matte Black Electric Guitar A B R Bridge Fast Ship Block Inlay Hh Pickup
One or more small-diameter bolts/machine screws are installed through the bridge and guitar top. These are generally positioned near the rear of the bridge, where the lifting force is greatest. Outside, the bolt head is typically hidden in a counter-bored section and covered with an inlay disc —sometimes pearl(oid), to make a feature of it, or a darker plastic disc to disguise it.
A guitar soundboard vibrates a lot. Over time, those vibrations can work the nuts loose. I’ve seen guitars with no nuts left (I like to imagine owners fishing small nuts out of the guitar and scratching their heads wondering how it got there).
I’ve also seen guitars with mysterious buzzes and rattles that worked hard to avoid being tracked down. Yep, you guessed it… rattling nuts and washers
Can You Play Slide Guitar On An Electric Sitar?
The guitar. When the nut is loose, but hasn't fallen off, that and the washer can make quite a buzzing as you play.
If you’ve a bridge like this and a weird buzz, it’s definitely worth checking to make sure all your bridge-bolt nuts are good and tight. Actually, if you’ve a bridge with reinforcing bolts, it’s worth doing this from time to time anyway. Those little bolts are doing an important job and you don’t want them becoming loose. If they become loose, your bridge might also become loose. Consider this regular, preventative maintenance.
An inspection mirror can make this a little easier but you can do this by feel. Look for those inlay dots at the back of your bridge and you’ll get an idea of how many bolts are present and where they’re located. Their ends will protrude from the guitar top/bridge plate inside. You should be able to feel if the nuts are nice and snug.
Causes & Solutions For Buzzing Guitar Strings That Actually Work
A word of caution. On guitars fitted with an under-saddle pickup, the pickup hook-up cable will also protrude from under the bridge. This can be delicate so be aware of it. Don’t go barging in with big ham-fists. 😉
If you do find a loose nut, getting it tight again can be a bit tricky. You may not have a nut driver or socket small enough. A small adjustable spanner/wrench can work but, while I wouldn’t normally recommend using a pliers for tightening nuts, I do find myself reaching for a small pair of pliers for this job.
The trick is that you’re just going to hold the nut securely with the pliers. The tightening will be done from the other end.
Seven Causes And Remedies For Guitar Fret Buzz
The inlays can generally be popped out relatively easily. If the nut is loose, you can use a small wooden block to butt against the end of the bolt inside the guitar. Then you can (carefully) push it up and this will often be enough to pop out the inlay. Use your other hand to apply some counter-pressure against the bridge area of the guitar top itself —this avoids stressing the top.
Alternatively (and a little safer if you’re unsure of the last method), you can use a sharp-pointed scribe or tiny screwdriver to work at the bridge around the disc so you can gain some purchase at the side of the inlay. Then you can lever it out.
Underneath, you’ll find the top of the bolt has a slot or Philips head. Gripping the nut inside and using a screwdriver from outside will get things good and snug. The inlay can generally just be pressed back into place.
Frequensator Tailpiece Buzz
As I write this, I’ve no idea why manufacturers don’t use some sort of Nyloc-type locking nut here. These things are subject to a lot of vibration and can use any help they can get to stay put. Next time I get one, I’ll try remember to check sizes and see if there are locking nuts available.
